The control system is divided into multiple control modules, such as the main control module, the spindle drive module, and the power transmission coil module. First, according to actual needs, starting from the aspect of reducing control costs and combined with the characteristics of embedded systems, such as tailorability, low cost, and strong scalability, this paper proposes a control system hardware structure based on CAN bus communication and a fully embedded STM32. This text carries on the systematic plan design to the control system from the hardware system and the software system. The integrated rapier loom control system based on the SRM spindle direct drive proposed in this paper reduces the production costs and energy consumption and improves the start-up performance and production efficiency of the rapier loom. The contribution and innovation of this paper is to develop a complete set of low-cost control systems, propose an SRM single neuron fuzzy PID speed control strategy based on voltage chopping control and use it for the control of the main shaft drive technology of rapier looms. To effectively reduce the production cost and energy consumption and to improve the start-up performance and production efficiency of rapier looms in industrial production, this paper develops an integrated rapier loom control system based on the direct drive of a switched reluctance motor (SRM) spindle and conducts field tests and applications.
The control system of the loom determines the performance of the loom, to a large extent. Rapier looms are currently important equipment in the weaving process.
